21
6-189.18
Table 21.1 - Deflector Hood General Performance
Data - Model BTP/BTS
Model
Size
Airflow
Temp
Rise
Mounting
Height
Blade
Angle
30° Hood 60° Hood 90° Hood
X Y Z X Y Z S
(cfm) (°F) (ft) (°) (ft) (ft) (ft) (ft) (ft) (ft) (ft)
150 2020 55
8 57 13 29 40 0 31 42 21
10 48 12 28 38 0 28 39 19
12 37 10 25 35 0 25 34 17
14 21 8 21 30 0 19 27 16
15 10 7 19 27 0 12 18 15
175 2357 55
8 51 11 24 33 0 25 34 17
10 39 9 22 31 0 22 30 15
12 22 7 19 26 0 17 23 14
13 2 5 14 21 0 10 14 13
200 2694 55
8 57 13 29 39 0 30 41 20
10 47 12 27 37 0 28 38 18
12 35 10 25 34 0 24 33 17
14 18 7 20 29 0 18 25 15
15 2 5 16 24 0 11 16 15
250 3367 55
8 59 14 31 42 0 32 44 22
10 50 13 29 40 0 30 41 20
12 39 11 27 37 0 27 37 18
14 25 9 23 33 0 22 30 17
15 15 7 20 29 0 18 25 16
300 4040 55
8 64 17 37 51 0 40 54 29
10 57 16 36 50 0 38 52 26
12 50 15 35 48 0 36 49 23
14 41 13 33 45 0 33 45 22
16 30 12 30 41 0 28 39 20
18 14 9 24 35 0 21 29 19
350 4714 55
8 63 16 36 49 0 37 51 27
10 55 15 34 47 0 36 49 24
12 47 14 33 45 0 33 46 22
14 37 12 30 42 0 30 41 20
16 25 10 27 38 0 25 34 19
18 2 6 20 29 0 13 19 18
400 5387 55
8 67 19 41 56 0 44 60 32
10 60 18 40 55 0 42 58 29
12 53 17 39 53 0 40 55 26
14 46 15 37 51 0 37 51 25
16 37 14 34 48 0 34 47 23
18 26 12 31 43 0 29 40 22
20 8 8 23 34 0 20 28 21
Note: Refer to Figures 20.1 through 20.3 on page 20.
PERFORMANCE DATA - HOODS FOR BTP/BTS BLOWER
MODELS
