Modine Manufacturing HD - STANDARD FEATURES AND FACTORY OPTIONS; Cabinet and Air Mover; Heat Exchanger and Burner; Controls

7
6-107.18
DO NOT LOCATE ANY GAS-FIRED UNIT IN AREAS WITH CHLORINATED,
HALOGENATED, OR ACIDIC VAPORS IN ATMOSPHERE.
Table 7.1 - Standard Features and Factory Options
Feature
Model Model Model
HD HDB PDP BDP
PTP
HDS HDC PTS BTS BTP PTC BTC
Cabinet and Air Mover
Aluminized steel cabinet (gauge indicated)
22 ga. 22 ga. 20 ga. 20 ga. 20 ga. 22 ga. 22 ga. 20 ga. 20 ga. 20 ga. 20 ga. 20 ga.
Low prole casing design
• • • •
Baked-on polyester powder paint for durability
and corrosion resistence
• • • • • • • • • • • •
Adjustable air-deector blades
• • • • • • • • • • • •
Fans engineered for quiet operation
• • • • • • • • • • • •
Totally enclosed fan/blower motors
(model sizes 100 and above)
• • • • • • • • • • • •
Fingerproof fan guard
(standard on sizes 125 and below)
• • Opt • • • Opt Opt
Two L-shaped mounting brackets
(standard on 30-75, optional on 85-125)
• • • • •
Adjustable mounting brackets for level hanging
• •
Hinged tool-less bottom pan entry
• •
Adjustable motor sheaves, certied to 0.7" W.C.
external static pressure
• • • •
Heat Exchanger and Burner
e󰀩ciency %
82% 82% 83% 82% 82% 82% 82% 82% 82% 82% 93% 93%
93% minimum thermal e󰀩ciency
• •
Aluminized steel heat exchanger
(409 stainless steel optional)
• • • •
SS
Std
• • • •
SS
Std
• •
Tubular heat exchanger
• • • • • • • • • •
In-shot burner on each heat exchanger tube for
reliable performance, ease of serviceability, and
low sound level on ame ignition/extinction
• • • • • • • • • •
Aluminized steel burner
(409 stainless steel optional)
• •
Modine Conservicore
®
Technology on
secondary recuperative heat exchanger with
AL29-4C
®
stainless steel material as standard
• •
Controls
CSA or ETL certication for commericial and
industrial use in the US and Canada
• • • • • • • • • • • •
CSA or ETL certication for residential use
in the US and Canada
• • • • 55-110
Factory-installed power exhauster
• • • • • • • • • • • •
Controls for natural gas (propane optional)
• • • • • • • • • • • •
Single stage gas controls
(two stage optional except for PTC/BTC)
• • • • • • • • • • • •
Supply air high limit safety controls
• • • • • • • • • • • •
Di󰀨erential pressure switch for proof of venting
• • • • • • • • • • • •
Flue gas high limit safety controls
• •
Flame roll-out safety switch
• • • • 55-110
Direct spark ignition with continuous retry
control system
• • • • • • • • • •
Intermittent pilot ignition with continuous retry
control system
• •
Control terminal board and low voltage
terminal connections
• • • • • • • • • • • •
Gas control step down transformer with
24V gas controls
• • • • • • • • • • • •
Fan delay timer
• • • • • • • • • • • •
Condensate drain overow switch
• •
Contractor convenience package featuring a
condensate pump convenience outlet, unit on/
o󰀨 switch, heater function status indicator lights,
and external terminals for thermostat wiring
• •
Factory install Building Managment Control
Opt Opt Opt Opt Opt Opt • •
STANDARD FEATURES AND FACTORY OPTIONS
