Modine Manufacturing MPR30 - D-Cabinet Size Unit with Energy Recovery

48 MCP15-500.9
DIMENSIONS - D-CABINET SIZE UNIT (WITH ENERGY RECOVERY)
97.39
100.50
100.75
(BASE)
104.25
(LUGS)
COMPRESSOR
COMPARTMENT
ACCESS DOOR
HIGH VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
180.73 123.36
SUPPLY AIR
BLOWER DOOR
FILTER & DAMPERS
ACCESS DOOR
57.19
137.16
263.68
(BASE)
GAS/ELECTRIC
HEAT (OPTION)
COMPARTMENT
ACCESS DOORS
GAS SERVICE
ENTRANCE
EVAPORATOR &
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
1-1/2" NPT EVAP
COIL DRAIN
PAN PIPE
CONNECTION
CONDENSING SECTION FAN QUANTITY:
(4) FANS FOR 30 AND 40 TON UNIT
(6) / (8) FANS FOR 52 AND 60 TON UNITS
ACCESSORY RAINHOOD
AND BIRDSCREEN
(FIELD INSTALLED ACCESSORY)
103.07
CONDENSING
SECTION
25.28
EXHAUST
HOOD
42.37
CONDENSER
SECTION
ERM
SECTION
306.10
126.81
101.53
BY-PASS DAMPER
REMOVABLE PANEL ASSY
FA FILTER & FA DAMPER
ERM DOOR ASSY
ERM CONTROL PANEL ASSY DOOR
99.61
40.58
15.50
(LUGS)
111.74
(LUGS)
120.94
(LUGS)
(6) 1.00" LIFTING LUGS
(4 - EACH CORNER OF UNIT)
(2 - IN BETWEEN UNIT & ERM SECTION)
GAS SERVICE
ENTRANCE
(8) TIE DOWN POINTS
(4 - EACH CORNER OF UNIT)
(4 - IN BETWEEN UNIT & ERM)
LOW VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
EVAPORATOR &
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
APPROXIMATE AREA
FOR SIDE ELECTRIC
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
ERM WHEEL & RA FILTER DOOR
FA FILTER & FA DAMPER
ERM DOOR ASSY
EXHAUST BLWR
SERVICE DOOR
ACCESSORY
EXHAUST HOOD
(FIELD INSTALLED)
INLET END VIEW
Figure 48.1 - Unit Dimensions (inches)
