Modine Manufacturing MPR30 - Model Nomenclature - Main Unit; Main Unit Model Nomenclature Table

64 MCP15-500.9
MODEL NOMENCLATURE - MODEL MPR
Table 64.1 - Model Nomenclature - Main Unit
Digits Indicates Description Value
Cabinet
B C D
1, 2, 3 Unit Type Commercial Packaged Ventilation Unit MPR ● ● ●
4, 5
Unit Nominal
Cooling
7, 10, or 13 ton 07, 10, 13 ●
15 or 20 ton 15, 20 ● ●
26 ton 26 ●
30 ton 30 ● ●
40, 52, or 60 ton 40, 52, 60 ●
6 Cabinet Size Refer to Dimensions B, C, D ● ● ●
7
Air Control
Conguration
OA & RA Dampers
No Exhaust A ● ● ●
Energy Recovery Exhaust B ● ● ●
Power Exhaust C ● ●
Barometric Relief Dampers R ● ●
OA Dampers (No RA) No Exhaust D ● ● ●
OA Dampers
(with Exhaust Opening)
Energy Recovery Exhaust E ● ● ●
Power Exhaust F ● ●
8 Evaporator Coil
High Capacity 4 Row, 14fpi
DX Coil
No E-Coat 1 ● ●
With E-Coat 2 ● ●
High Capacity 6 Row, 14fpi
DX Coil
No E-Coat 3 ●
With E-Coat 4 ●
9
Compressor
Staging
Tandem Digital Scroll (Digital Modulating + On/O󰀨) (10-30 ton units) A ● ●
Single Digital Scroll (Modulating Digital) (7 ton units only) B ●
Dual Tandem Digital Scroll [(Digital Modulating - On/O󰀨) & (On/O󰀨 - On/O󰀨)] D ●
10
Hot Gas
Reheat
No Hot Gas Reheat 0 ● ● ●
Modulating Hot Gas Reheat 1 ● ● ●
Modulating Hot Gas Reheat with E-Coat 2 ● ● ●
11
Condensor
Arrangement
VFD Head Pressure Control
Microchannel Coils A ● ●
Microchannel Coils with E-Coat (UV) B ● ●
Modulating EC Motor Head Pressure
Control (30, 40 Ton)
Microchannel Coils E ●
Microchannel Coils with E-Coat F ●
Modulating EC Motor Head Pressure
Control (52, 60 Ton)
Microchannel Coils G ●
Microchannel Coils with E-Coat H ●
12
Supply Fan
Conguration
(Direct Drive
Plenum Fan)
Wheel Size (inches) Fan Type
11 Non-Airfoil Fan (ANPL) K ●
12 Non-Airfoil Fan (ANPL) L ●
12 Airfoil Fan (ANPA) 4 ●
14 Airfoil Fan (ANPA) 7 ●
16 Airfoil Fan (ANPA) 8 ● ●
16 x 2 Dual Airfoil Fans (ANPA) E ●
20 Airfoil Fan (ANPA) A ● ●
25 Airfoil Fan (ANPA) C ● ●
25 x 2 Dual Airfoil Fans (ANPA) J ●
13
Supply Fan
Motor HP
(includes VFD)
1 HP Q ● ● ●
1-1/2 HP R ● ● ●
2 HP S ● ● ●
3 HP T ● ● ●
5 HP U ● ● ●
7-1/2 HP V ● ● ●
10 HP W ● ● ●
15 HP X ●
20 HP Y ●
14 Fan Motor Type
Motor Type Supply Fan Motor RPM Exhaust Fan Motor RPM
ODP
1800
1800 or N/A 1 ● ● ●
3600 3 ●
1200 5 ●
3600
1800 or N/A A ● ● ●
3600 C ●
1200 E ●
1200
1800 or N/A G ● ● ●
3600 J ●
1200 M ●
TE
1800
1800 or N/A 2 ● ● ●
3600 4 ●
1200 6 ●
3600
1800 or N/A B ● ● ●
3600 D ●
1200 F ●
1200
1800 or N/A H ● ● ●
3600 K ●
1200 P ●
(continued next page)
