Manual MODSTER EC-135
28 www.modster.at
Helicopter Parameters
Length 352 mm
Height 120 mm
Weight 383 g
Main Rotor Diameter 328 mm
Tail Rotor Diameter 70 mm
Battery Specifications 7,4V 1200mAh 25 C
Flight Time 8-10 Min
Main Brushless Motor 2507
Brushless Tail Motor 1204
Battery Charging
1� Connect the USB cable to a computer USB port or a power adapter�
2� Connect the USBs other end (Type-C plug for Android) to the battery for charging�
3� During charging, the current battery level indicator will flash, and all our lights will
remain solid when charging is complete�
4� Disconnect the charging connection after charging is complete�
5� Note: It is recommended to use a 5V 2A adapter for charging, as it
