Customer Service 908-368-1025︱ Page 4 of 11
STEP 2:
STEP 3:
PM1x4
PM1
Px16
Hardware required.
Screwdriver not included
EEI-2531 SIDEBOARD
Tx1
www.modway.com
2
2
Ax4
Bx8 Sx4
Hardware required.
Screwdriver not included
Tx1
1
3
3
B
4
5
S
Securing the Leg Mounting Plate ( O )
to the Bottom Board (2)
Flip the Bottom Board then the Connecting
Hardware assembly, Cambolt (A) on it.
Securing Side Boards ( 3 )x 2 pcs, Center Board
Left (4) and Center Board Right (5) on to Top
Board using Camlock (B), then finish it with
Screw Cap (S).
To Next Page
