Customer Service 908-368-1025︱ Page 8 of 11
STEP 9:
STEP 10:
Ax2 Ex2
Cx2 Nx4
EEI-2531 SIDEBOARD
Hardware required. Screwdriver not included
Tx1
Hardware required. Screwdriver not included
Tx1
www.modway.com
Drawer Box parts
Connecting hardware assembly -
Securing Assembly Cambolt (A)
to 1 of the Drawer Front (9), then
Small Dowel (E) to Side Drawer
Left (10) and Side Drawer Right
(11)
Drawer Box assembly
Securing both Side Drawer Left (10) and Side Drawer Right (11) to the Drawer
Front (9) using Small Camlock (C).
Then Slide in Bottom Drawer (13) with laminated side facing inside box. Finish with
securing Back Drawer (12) using Screw (N)
To Next Page
