PAGE 2 OF 13780-161MD2-0
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
For vanity and plumbing installation, we suggest hiring a professional
contractor and plumber.
Assemble your item on a fl at, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your fl oors or the item while
you’re assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suff ocation.
Provided hardware:
Furniture components:
What you need:
You may also need:
E
F
G
H O
I P
J Q
K R
L
M
N
A
x16
x4 x4
x1 x2
x2
x40
x2
x4 x6
x1 Pair
x1 Pair
x26
x8
x1
Wood Dowel M8 x 25mm
Corner Bracket
Wood Dowel M6 x 25mm
B
x19
Cam Bolt Ø6 x 24mm Bracket-L/Hanger Door Hinge (Half Overlay)
D
x16
Screw 9 x 38mm
C
x11Cam Lock Ø15
Phillips Head Screwdriver
+ Power Drill
+ Level
+ Silicone Adhesive or Caulk
+ Drywall Anchors and Screws
+ Other Wall-Mounting Hardware
Screw 4 x 25mm
Screw 4 x 14mm
Door Hinge (Full Overlay)
Screw 4 x 28mm
Rubber Pad
Bearing Runner
400mm
Screw 4 x 12mm
Cam Lock Ø12
Bracket-R/Hanger
Bearing Runner
300mm
Phillips
x1 x1
x1 x1
x1 x1
x1
x1
x1 x1
1
11
x1 x1Drawer Front 1
2 1x 21 x1Right Side Panel Drawer Front 2
3 1x 31 x1Bottom Panel Drawer Front 3
5 15
7
17
8 18
x1 x14 14Back Panel 1 Drawer Side L 1
Back Panel 2 Drawer Side R 1
x1 x26 16Front Support Drawer Back
Support Panel
Drawer Panel 1
Center Panel Drawer Side L 2
9 19
10 20
Drawer Side R 2
Door Panel Right Drawer Panel 2
Approx. 90 minutes
assembly time
2 people recommended
for assembly
Care instructions are
listed in the last step
of this manual
Read through all of
the instructions
before starting
Make sure you have all
parts and components
before discarding any
packing materials
L
et’
s get s
tar
ted!
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
