Is the cabinet not hanging quite right?
Here are some adjustment tips.
Wall Bracket Installation Guide
Cabinet-to-Wall Installation Guide
Measurement Guide
All units are in millimeters.
14.5 Set the hanger
latch as shown.
If your cabinet isn’t level, follow this guide.
If your cabinet is pulling away from the wall, follow this guide.
14.6 Hook cabinet
onto latch.
14.9 Once the cabinet is
installed and adjusted,
install the latch covers.
14.7 Push cabinet
down onto latch.
Adjustment Screw A Adjustment Screw B
14.8 Fasten the hanger’s
latch with the screw.
14.3 Install bracket with 3 screws.
Repeat with other brackets.
14.1 Use a drill to make all pilot holes.
14.4 Ensure your bracket measurements are correct
before moving on to attaching the cabinet to the wall.
14.2 Insert a Drywall Anchor
into each of the nine holes.
S
t
ep 14
