Intelligent slaves
53
04/99 AWB 27-1184 GB
You can derive the syntax for sending and receiving
the data from the configuration.
Table 12: Syntax for addressing intelligent slaves (data
type: word)
IL program
in ...
Data flow Ope-
rand
Data
type
Line Sta-
tion
Module Byte/
word
Bit Syntax
Master Master
←
Slave
Master
→
Slave
RDW/
SDW
Word 1 1 0 0 – RDW1.1.0.0/
SDW1.1.0.0
Slave Slave
←
Master
Slave
→
Master
RDW/
SDW
Word 0 0 0 0 – RDW0.0.0.0/
SDW0.0.0.0
