Software Configuration
44
04/99 AWB 27-1184 GB
Configuration example This example requires topology configurations for
the master (device A) and the intelligent slaves
(devices B and C).
Figure 19: Configuration example
Master: Device A
Intelligent slaves: Devices B and C
Slave for expanding the remote I/O: D
Note that intelligent slaves are configured twice -
once in the master’s configuration and once in
the slave’s own configuration.
PS 4-201-MM1
PS 4-151-MM1
PS 4-201-MM1
EM 4-201-DX2
LE 4-...
LE 4-...
LE 4-...
LE 4-...
LE 4-...
LE 4-...
Line 1
Device A
Device C
Station 2
Device
B
Station 1
Device
D
Station 3
