Moen M-CORE 4 Series How To Adjust

Parts Legend:
The images in this instruction
guide are shown with all of
the decorative trim (Handle,
Decorative Sleeve and
Escutcheon Back
Plate) removed. It is only
necessary to remove the
Handle for this process.
A-Cartridge
Nut (Hexagonal Brass
Nut)
B-Cartridge Ring
C-Cartridge Stem
D-Temperature Limit
Stop (White plastic
with small square tab)
E- Retainer Ring
(Black O-ring)
**Caution: Do not
remove or loosen the
Cartridge Nut (A). The
Cartridge Nut (A) is
what holds the
brass Cartridge in place
and retains the water in
https://solutions.moen.com/Article_Library/How_to_Adjust_the_M-Core_4_Series_Temperature_Limit_Stop
Updated: Fri, 28 Jun 2024 08:16:22 GMT
Powered by
2

Moen M-CORE 4 Series Specifications

General

Brand	Moen
Model	M-CORE 4 Series
Category	Plumbing Product
Language	English
