INS10513 - 10/16
5
Finished Wall
Pared terminada
Mur ni
13" ± 1/4"
330mm ± 6mm
1-13/16"
46mm
Wood Support
Soporte de madera
Support en bois
Stud
Montante
Montant
Electrical Outlet (GFCI)
Tomacorriente (GFCI)
Prise électrique (DFT)
2-7/32"
56mm
Mounting Dimensions / Dimensiones de montaje / Dimensions de montage
Access Panel Side
Lado del panel de acceso
Côté du panneau d'accès
Shower Side
Lado de la regadera
Côté de la douche
