4.2: Electrical Specification
CR5
CR10
CR20
CR5C
CR10C
CR20C
Rating (kw) Supply Voltage Amps per phase
2.9
4
6
9
12
2.9
4
6
9
12
230
400
400
400
400
230
400
400
400
400
13
16 3PH or 32 1PH
16 3PH or 32 1PH
16 3PH or 45 1PH
20 3PH or 63 1PH
13
16 3PH or 32 1PH
16 3PH or 32 1PH
16 3PH or 63 1PH
32 3PH or 63 1PH
Live (L1)
L2
L3
Neutral
Earth
1 Phase Cable (1PH) 3 Phase Cable (3PH)
Brown
X
X
Blue
Yellow & Green (Striped)
Brown
Black
Grey
Blue
Yellow & Green (Striped)
This appliance must be earthed!
Damaged cables must be replaced
by a suitably qualified person!
