30 Appendix A. Specifications
Parameter Specification
Thermal
TEC ±14.5V3.3A Q =23W standard
Sensor NTC 10kΩ standard; AD590, 592 optional
Stability at base ±1mK(controller dependent)
Cooling Optional:4mmdiamquick-fitwatercooling
connections
Electronics
Protection Diode short-circuit relay; cover interlock
connection; reverse diode
Indicator Laser ON/OFF(LED)
Connector MOGLabsDiodeLaserControllersingleca-
ble connect
Modulation input Active(AC andDCcoupled)orRF biastee
Mechanical & power
Dimensions 108× 70× 83mm (L×W×H), 1kg
Beam height 58mm
Shipping 420× 360× 260mm (L×W×H), 3.1kg
