MOGlabs CEX User Manual

A. Specifications
Parameter Specification
Wavelength/frequency
368 – 1620nm Diode dependent.
Please contact MOGLabs for availability.
Linewidth Typically < 100kHz
Filter 0.2 to 0.4nm bandpass
Tuning range Diode dependent; 5nm to 50nm
Sweep/scan
Scan range 20 to 30GHz
Mode-hop free 5 to 30GHz
Piezo 5− 9µm @ 150V, 200-350nF (typical)
Cavity length 22mm
Optical
Beam 3mm× 1.2mm (1/e
2
) typical
Polarisation Vertical linear 100:1 typical
29
