A.1 CEL mechanical (Rev9+) 31
A.1 CEL mechanical (Rev9+)
70
58
86.7
108
50.5
50.5 13.7
9.7
4 x M6 clearance
Figure A.1: Dimensions of CELlaser head (Rev9+).
