SECTION 4:
COMPONENT IDENTITY & ORIENTATION
ENSURE ALL POLARIZED CAPS ARE IN THE CORRECT ORIENTATION WHEN INSTALLING ONTO THE BOARD. THIS IS TYPICALLY DENOTED BY AN ARROW POINTING TOWARDS THE NEGATIVE
SIDE, OR A SMALL INDENTION ON THE POSITIVE SIDE.
SAFETY FIRST! A CAP IN THE WRONG ORIENTATION CAN EXPLODE! SO FOLLOW YOUR WIRING DIAGRAM AND PAY CLOSE ATTENTION WHEN ORIENTING YOUR POLARIZED CAPS.
POLARIZED
NON-POLARIZED
Carbon Composite
Silver Mica
Mojotone Dijon
(2) Rubber
Grommets
(2) Ground
Tabs
(2) Four-Lug Terminal
(1) 1/4'' Mono Plug
(1) Fuse Holder & Fuse
w/ hardware
(2) Toggle Switch
w/ hardware
Jacks w/ hardware
(4) J1 4-Lug Jack
(1) J2 2-Lug Jack
(8) Knobs
RESISTORS CAPACITORS
HARDWARE
WIRES
20 gauge Pre-Tinned PVC Coated Wire (4‘ of each color)
Copper Bus Wire (2‘)
(20) 4-40
1
/
4
'' Screw & Keps Nuts
Standoffs for Turret Board
Red
Blue
Yellow
Green
Gray
Black
(2) 8-32
1
/
4
’’ Screw & Keps Nuts
(2) 6-32
1
/
2
’’ Screw & Keps Nuts
(4) 10-32 1
1
/
2
’’ Screw & Keps Nuts
Wire Wound
(2)
1
/
2
W 1M
(1)
1
/
2
W 10K
(1)
1
/
2
W 2.7k
(1) 4.7nf @ 630V
(1) Mojotone
Electrolytic KingCap
16µf @ 475V
(2) Sprague Atom
25µf @ 50V
(2) Can Capacitor
32µf + 32µf
@ 500v
(2) Can Capacitor
Clamps
(4) 10nf @ 630V
(5) 22nf @ 630V
(1) 680nf @ 160V
(1) 47pf @ 500V
(2) 500pf @ 500V
(2) 2W 10kΩ
(2) 2W 2.7k
(1) 3W 130Ω
(2)
1
/
2
W 5.1k
(1)
1
/
2
W 47k
(3)
1
/
2
W 68k
(7)
1
/
2
W 100k
(7)
1
/
2
W 470k
(3)
1
/
2
W 820Ω
(2) 1W 100Ω
Metal Oxide
