MX123 Connection System User Manual - AS-34566-001 11
Section 2: Product Summary
6.3mm Receptacle Terminal
(Aptiv Terminal and Cable Seal)
P/NXXXXX Aptiv 6.3mm RCPT TERM Tin 14 Cable Seal
Two (2) possible orientations of receptacle terminal during insertion to
connector
Conductor crimp
up
Conductor crimp
down
No Orientation Tabs
