MX123 Connection System User Manual - AS-34566-001 12
Rectangular cross-section to
prevent mis-orientation into
the grommet seal cover.
Shoulder area provides
forward stop.
Sealing surface
Lock tabs to provide seal
plug retention to
grommet seal cover.
Rectangular head for ease of
removal from grommet seal
cover.
Section 2: Product Summary
Grommet Seal Plug – Features
Molex Part 34586-0001
