MX123 Connection System User Manual - AS-34566-001 13
Section 2: Product Summary
Parts “As Shipped”
80 circuit connector shown – typical for all circuit sizes
Harness connector
assembly shipped with TPA
& lever in pre-lock position.
Lever will remain in pre-lock
until mated with
header/controller, or a force
over 190N is achieved.
If lever moves freely from
pre-lock position without
being mated to
Header/Controller:
Do Not Use Connector!
Dress Cover Shipped
Separately.
