MX123 Connection System User Manual - AS-34566-001 29
C. Harness Connector to Header/Controller Mating To Final Lock (continued)
Continue to rotate the lever until you hear the primary latch click into final lock
over dress cover primary latch (Fig. 4-7a and 4-7b).
Primary Latch Engaged
Dress Cover Primary Latch
Fig. 4-7a Fig. 4-7b
Section 4: Connector Mating Instructions
