1.0 OVERVIEW
The Pocket Laser Tach 200 is a multifunction Tachometer, Ratemeter,
Totalizer and Timer. It is programmable to read in English or Metric units.
An input socket accepts remote sensing devices and an output socket allows
for pulse output to external indicating devices. The PLT200 can be tripod
mounted and “Locked-On” for accurate and continuous operation. This
tachometer also stores minimum, maximum and last measurement in memory.
2.0 FEATURE LOCATIONS
Min / Scroll
Down arrow
Start / Reset button
Max / Scroll Up
arrow
LCD display
Menu / Select
and Lock-on
button
Battery compartment
AVOID EXPOSURE - LASER BEAM IS
EMITTED FROM THIS APERTURE
Output socket
Input socket
Belt clip
Tripod mounting bushing
(underside)
