5.3 Connecting External Sensors
Plug sensor into
Input socket
Tighten screw
securely into fl at
on shaft.
Install with
pin in shaft
fully seated
in slot.
Tighten
screw.
2. 10 cm Wheel 3. 12 inch Wheel
OR
Remote Contact
Assembly (RCA)
(shown with optional 12 inch wheel)
In
p
Remote Optical
Sensor (ROS-P)
Infrared Sensor
(IRS-P)
Magnetic Sensor
with Amplifi er
(MT-190P)
