6.0 TAKING MEASUREMENTS
6.1 Non-Contact Measurements
6.2 Direct Contact Measurements
6
Hand-held
Laser
External Sensor (ROS shown)OR
Light
WARNING: Making measurements in direct contact with rotating
equipment can be dangerous. Keep all loose clothing and hair away from
exposed moving machinery. Keep the hand holding the instrument well
behind the back end of the Remote Contact Assembly. Properly replace
all machinery guards after completing measurement. Do not use for
rotation greater than 20,000 RPM.
to RCA
from PLT200 from PLT200
Rotational Linear
(Use concave
tip for small
shafts)
ONLY USE MODERATE PRESSURE
To Next Page
