Monarch 9820 - Daughter Board Connectors; Figure B- 10. CN 11; Figure B- 15; Figure.b- 9. CN

Connectors and Cables 9830/9835 Service Manual
July 1998 TC9830SM Rev. B 7/98 Confidential 55
1 TDX ANODE
2 TDX COMM
Figure B- 10. CN 11
GND
Two-wire harness connect red wire to TP5 (+25 volts)
Figure B- 11. CN 14
1 RT_MTR_1
2 RT_MTR2
Figure B- 12. CN 15
1 RS_MTR_1
2 RS_MTR2
Figure B- 13. CN 16
1 +12V
2 GND
3 -12v
4 GND
5 _NO_RAT( +25V)
6 GND
Figure B- 14. CN 19 (to Daughter Board CN3)
Daughter Board Connectors
1 +12V
2 GND
3 -12v
4 GND
5 _NO_RAT( +25V)
6 GND
Figure B- 15. CN 3 To MotherBoard CN 19
1 PEEL_MFTR_1
2 PEEL_MFTR_2
Figure B- 16. CN 10 Peel Motor
1 _OD_A
2 OD_K
3 +12V
4 OD_E
5 GND
6 N/C
Figure B- 17. CN 6 On-Demand Sensor
