Model 928 Stacker 9820/9830/9835 Service Manual
July 1998 TC9830SM Rev. B 7/98 Confidential 61
Table D- 2 Jam/Full Sensor Harness.
Control Board CN3 Pin Full Sensor (S1) Pin Jam Sensor (S2) Pin
1 2
2 2
3 N/C
4 KEY
5 1
6 3
7 3
8 1
9 4
10 4
Table D- 3. Extended Motor Interface Harness.
(Soldered to Control Board Connector CN4)
Extender Connector Pin Signal Stepper Motor Connector Pin
1 1
2 2
3 +24 Vdc 3
4 +24 Vdc 4
5 5
6 6
Table D- 4. AC Power Harness.
Power Supply Connector J1 Signal Power Switch (SW1)
Pin Terminal
1 GND
2 N/C
3 115 VAC 1
4 N/C
5 N/C
Table D- 5. Power Supply Connector J2.
Connector J2 Pin Signal/Pin Control Board Connector CN2 Pin
1 (Orange) 4
2 N/C
3 N/C
4 (Brown) 5
5 (Green/Yellow) GND
6-13 N/C
