Setting of terminal
When using a handheld controller (Art. No: 9339-51)
do as follows:
First, perform "Setting the command type (PC or 1.
ECG)" and select 0.
Connect the terminal to the bike using the 2.
enclosed cable.
Connect power to the bike. 3.
When the main menu is displayed on the LCD-4.
screen press 99 and the hidden service menu
appears.
Press 6, ”Settings”.5.
Press ENTER (normally 13 times) until the 6.
display ”Command type” appears.
a) Press 1 and ENTER if the bike is connected
to a Siemens Megacart ECG device.
b) Press 2 and ENTER if the bike is connected
to a Siemens Megacart ECG device, alt. 1.
c) Press 3 and ENTER if the bike is connected
to a Siemens Megacart ECG device, alt. 2.
d) Press 0 if the bike is connected to a PC or a
handheld controller.
7. After that press 0 twice to go back to main
menu.
