Monark 939 E - Spare Parts List

1
11
3
2
22
13
14
15
16
17
18
19
20
21
10
9
8
7
6
5
4
12
Monark 939 E
24
Spare parts list
From serial number WBK 285590H
Pos. Qty. Art. No. Description Pos. Qty. Art. No. Description
1 1 9300-24 Wheel suspension complete set 13 1 9328-62 Stop
2 1 9300-3 Flywheel 14 1 9338-19 Stay
3 1 9328-64 Brake belt, complete 15 1 9338-17 Adapter servo
4 2 9300-99 Plastic stop 16 3 14323 Screw M6x16
5 1 9338-29 Contact plate 17 1 9338-57 Tension device, complete
6 1 9338-28 Bracket for box 18 2 9338-15 Bracket for servo
7 1 9338-31 Contact, complete 19 2 9338-16 Bracket for servo
8 1 9338-24 Electronic box 20 1 9338-1 Frame
9 1 9338-30 Cover plate 21 1 9338-58 Switch, “on”/”off”, with cable
10 1 9338-142 Contact bracket, complete 22 1 9328-33 Adaptor M20/M16
11 1 9328-100 Pendulum, complete 1 9339-39 Communication cable, 3 m
12 1 9328-29 Scale lock, complete 1 9339-67 Power adaptor
