Monark 939 E
5
Facts
Controlled digital by ECG or PC with RS232 •
cable
Connection of RS 232 cable in floor level•
Large, well-balanced flywheel, 20 kg (44 lbs) •
Pendulum scale, easy to calibrate•
Constant power mode•
Workload 0-1400 W (depending on rpm)•
Adjustable saddle with quick release lever•
Adjustable handlebar with quick release lever•
Stable frame, solid steel tube•
Rust protection and powder paint•
Wheels for easy transport•
Display that shows RPM•
Width
550 mm (20”) at handlebar
620 mm (25”) at support tubes
Length
1240 mm (49")
Height
1260 mm (20”) at handlebar
790-1160 mm (31"-46”) at seat
Weight
58 kg (127,8 lbs)
Max user weight 250 kg (551 lbs)
Included
Calibration weight 4 kg•
Chestbelt for pulse detection (only PC-model)•
USB - serial adaptor (only PC-model)•
Power adaptor•
Tool kit•
Technical data power adaptor
Input voltage: 220-240V AC, 50/60Hz.
Current: 650mA.
Output voltage: 24V DC switching adaptor alt. 18V
AC.
(Sweden, 18V, Art. No: 9339-67, other countries incl.
USA, 24V, Art. No: 9339-66)
NOTE! The power adaptor must be approved by
your national electrical authorities. In Europe, it must
be CE marked.
Product Information
Congratulations on your new Ergometer!
The Monark 939 E is designed to perform stress tests
when connected to an ECG device. When connected
to a PC or terminal, the bike can be used to perform
Max and SubMax cardiovascular tests, calculate VO
2
capacity and more. The bike can also be used for
normal exercise.
Each 939 E is calibrated at the factory. This means
that you can begin to use the ergometer directly after
assembly. But as usual when the bike has been moved,
an electronic calibration must be done, see instruction
for “Calibration” in this manual.
Fig: Serial number (1)
NOTE!
Use of the product may involve considerable
physical stress. It is therefore recommended that
people who are not accustomed to cardiovascular
exercise or who do not feel completely healthy,
should consult a physician for advice.
Serial number
The serial number is placed according to Fig: Serial
number.
PC software
If you need a pc software to do exercise tests on the
bike, our software is available for free download from
our website: www.monarkexercise.se.
