Moneual MR6550 - Cleaning the dust inlet

40 MR6550 User Manual
ENGLISH
Cleaning the dust inlet
01. Remove the dust inlet cover.
02. Remove the main brush by holding and lifting it.
03. Clean the removed main brush with a cleaning brush.
04. Insert the main brush back.
Check the groove shape and insert it into the fixing hole of the rubber brush. Then, fix the wing of the
fixing pin to the robot.
