6
AirStream 10
After successful entry of these details, the display will change to ‘Please wait
connecting.’, and then ‘Connected’ will be displayed.
Note:
If your network name or SSID has been hidden, the AirStream 10 will not be able to
find it. You can either turn on the SSID of your access point and then select ’[Rescan]’
or enter the SSID into the AirStream 10. To enter your SSID into the AirStream 10,
select ‘[Manual config]’ as below, then ‘DHCP Enable’, ‘Wireless’ and then enter your
SSID, see page 4 for key entry. After you have entered your SSID, either select ’Open’
if you have no further security on your network or proceed to enter your WEP or WPA
codes. Your AirStream 10 will now connect to your network as in Step 4 (above).
Note:
In addition to the list of available networks there are three advanced options:
Rescan - • To scan again for available networks
Wired - • Which selects a ’wired‘ or ‘Ethernet’ network
Manual config - • Which enables you to manually set up the wireless configuration
including SSID and WEP/WPA codes.
If you are using the wired connection method, then you just need to select it 8.
from the Network Wizard menu, it will then run through the connection process
and the following will be displayed. If it doesn’t work first time around, go to the
‘Manual settings’ in the ‘Network settings’ menu and select the ‘Wired’ option,
then ‘DHCP enable’
Note:
For privacy reasons, you should only connect to wireless access points that you own
or have agreement to use.
Note:
The security details must be the same as those saved in the wireless access point,
which would have been set up by the person who installed your wireless network.
Note:
Make sure that the letter, number or symbol you wish to select is flashing in the display
before you press the ‘Tune/ Select’ knob to select it.
Note:
WEP and WPA codes are sensitive to upper and lower case characters so you must
enter them exactly as they have been stored in the wireless access point.
Advanced Users
It is possible to edit all of the settings for your internet connection. To access this
menu:
Press ‘Menu’ and use the ‘Tune/Select Dial’ to scroll to and select ‘Main Menu’.1.
Use the ‘Tune/Select Dial’ again to scroll to and select ‘System setup’, followed 2.
by ‘Internet setup’ and then ‘Manual settings’.
Within this same menu list you can select ‘View settings’, which enables you to 3.
see the current settings for:
MAC address DHCP•
PC settings SSID•
IP settings, which displays the IP address, subnet mask and gateway address.•
Software Update
It is recommended that you perform a software update before proceeding any further.
Please go to page 23 for information on how to do this.
Network settings
Please wait.
Connecting...
1
2
3
4
Network settings
Please wait.
Connecting...
1
2
3
4
Network settings
Connected
R
1
2
3
4
Network settings
Connected
R
1
2
3
4
