Your Bronze BR1
The BR1 remains the ‘baby’ of the Bronze Reference Series. Improved driver
and tweeter technologies help to propel the BR1 ahead of its predecessor.
Overall bandwidth has been increased withusablefrequency response right out
to 30KHz. Improved motor system linearity has resulted in lower distortion and
low frequency damping. The BR1 is now single wired, but improved terminal
quality liftstheoverall desirability of this entry level monitor.
Because the BR1 offers huge performance from a small speaker, it lends itself
to a wide range of positioning options. The BR1 will perform equally well no
matter how it is positioned. The BR1 can be placed on a stand, on a book-shelf,
it can evenbe hung on a wall usinga wall bracket (not supplied). The BR1 has a
¼” UNC threaded insert in the back of the cabinet to allow it to be wall
mounted. Please note that when using a wall bracket we would recommend
using the enclosed port bungs to eliminate ‘bass boom’ and unwanted air
turbulencecausedby the bracket.
Frequency
Response
Sensitivity
(1W@1m)
Nominal Impedance
(Ohms)
Power
Handling
RMS (W)
Recommended
AmplifierPower
Output.
55Hz – 30KHz 88dB 6 70 15 - 70W
Drive Unit
Complement
Cabinet
Design
Product External
Dimensions
cm (inch)
Weight
(packed)
Kg (lb)
Finishes
1x 5.5" MMP
®
Mk2
Bass mid-range.
1x 25mm Gold Dome
C-CAM
®
tweeter.
Rear ported,
bass reflex
26H x 16.5W x 18D
(10 ¼ x 6 ½ x 7
1
/
16
)
8.7 (19.1)
Black Oak,
Walnut, Cherry.
