6
Rev3. © Monitor Audio 2006
Your Bronze BR5
BR5 is new to the Bronze Reference Series. The cabinet profile is now slimmer
than its predecessor to offer a more desirable foot print for a typical life-style
setting. The new 5.5” bass drivers replace the 6.5” bass drivers of the B4.
However, bass extension and punch have been maintained and even improved
in terms of overall control. The 2 ½ way design is now optimised with the bass
and bass/ mid-range drivers working in dual chambers, similar to the more
advanced MA designs. Cabinet bracing has been up rated and results in very
rigid construction producing a clean, ‘un boxy’ character. The floor-level
mounted terminal panel now allows easy access without un-necessary trailing
cables.
Unlike the BR2, the BR5 has a reflex port at the rear as well as the front. This is
to provide maximum airflow at low frequencies and reduces air pressure that
can lead to bass compression effects.
Frequency
Response
Sensitivity
(1W@1m)
Nominal Impedance
(Ohms)
Power
Handling
RMS (W)
Recommended
AmplifierPower
Output.
36Hz-30KHz 90dB 6 120 30 - 120W
Drive Unit
Complement
Cabinet
Design
Product External
Dimensions
cm (inch)
Weight
(packed)
Kg (lb)
Finishes
1x 5.5" MMP
®
Mk2
Bass,1 x 5.5" MMP
®
Mk2 Bass mid-range.
1x 25mm Gold Dome
C-CAM
®
tweeter.
Dual Chamber
Bass Reflex.
PortedFront
and Rear.
85H x 16.5W x 24.7D
(33
7
/
16
x 6 ½ x 9 ¼ )
14 (30.8)
(Packed
Individually)
Black Oak,
Walnut, Cherry.
