119
E
Frame
Chromium-molybdenum tubular trellis frame, cast aluminium
rear subframe
Steering angle (on each side):
32°
Steering head angle:
24°
Trail mm:
87
Wheels
Three-spoke, light-alloy rims.
Front
Make:
BREMBO
Dimensions:
MT3.50x17”.
Rear
Make:
BREMBO
Dimensions:
MT4.50x17”
Both wheels have removable axles.
Tyres
Front
Radial tubeless tyre.
Size:
120/60-ZR17”
Rear
Radial tubeless tyre.
Size:
160/60-ZR17”
Suspensions
Front
Hydraulic upside-down fork.
Leg diameter: 43 mm.
Travel along fork leg axis: 120 mm
Rear
Progressive monoshock with adjustable rebound,
compression and spring preload:
Shock absorber stroke: 59.5 mm.
Rear wheel travel: 148 mm.
Note
Do not carry out any operations on the motorcycle that
could modify the technical characteristics for which approval
was obtained.
