Refitting the battery
Important
To refit the battery, ALWAYS contact a Ducati Dealer
or authorised Service Centre.
Install the battery in the battery support and secure it with
the elastic retaining strap (19).
Warning
Connect the positive lead (20) and the ABS positive
lead (23) to the positive terminal and the negative lead (21) to
the negative terminal, as shown in the photo.
Insert the screws (22) in the terminals (20) and (21), always
starting with the positive terminal (red lead).
Warning
Position the leads (20), (21) and (23) as shown in the
photo.
Tighten the screws (22) to a torque of 10 Nm ±10%.
Apply grease around the battery terminal clamps to prevent
oxidation.
