Monster 659 - Page 93

92
E
Secure the tank to the subframe with the screw (14) and the
washer (15).
Tighten the screw (14) to a torque of 10 Nm ±10%, using a
5 mm Allen wrench to counterhold the threaded insert (M)
located on the upper part of the tank.
Important
The threaded insert (M) is not present in the USA
version.
14 15
M
fig. 93
Upper view
Lower view
