Switching outputs Type Switching contact
Only in housing size
72x36 mm
Relay with
change-over
contact
250 VAC / 5 AAC; 30 VDC / 5 ADC
30 x 10
3
bei 5 AAC, 5 ADC at ohm resistive
burden
10 x 10
6
mechanically
Separation according to DIN EN50178 /
Characteristics according to DIN EN60255
14
8. Technical data
Accuracy
Temperature drift 100 ppm / K
Measuring time 0.1…10.0 seconds
Measuring principle U/F-conversion
Resolution approx. 18 bit at 1s measuring time
Power pack 230 VAC ±10 % max. 3 VA
24 VDC ±10 % max. 1 VA
Memory EEPROM
Data life ≥ 100 years at 25°C
Ambient conditions
Working temperature 0°C…60°C
Storing temperature -20°C…80°C
Weathering resistance relative humidity 0-80% on years average without dew
EMV EN 61326
CE-sign Conformity to directive 2014/30/EU
Safety standard According to low voltage directive 2014/35/EU
EN 61010; EN 60664-1
