montwill M1 User Manual

8. Technical data
Housing
Dimensions 96x48x25 mm (BxHxD), D = 38 mm including plug-in terminal
96x24x60 mm (BxHxD), D = 74 mm including plug-in terminal
72x36x71 mm (BxHxD), D = 100 mm including plug-in terminal
48x24x27 mm (BxHxD), D = 54 mm including plug-in terminal
Panel cut-out 92.0
+0.8
x 45.0
+0.6
mm (Housing 96x48 mm)
92.0
+0.8
x 22.2
+0.3
mm (Housing 96x24 mm)
68.0
+0.7
x 32.0
+0.7
mm (Housing 72x36 mm)
45.0
+0.6
x 22.2
+0.3
mm (Housing 48x24 mm)
Insulation thickness up to 3 mm
Fixing snap-in screw element
Material PC Polycarbonate, black, UL94V-0
Sealing material EPDM, 65 Shore, black
Protection class standard IP65 (front), IP00 (back side)
Weight approx. 100 g (96x48 mm, 96x24 mm, 48x24 mm)
approx. 200 g (72x36 mm)
Connection plug-in terminal; wire cross section up to 2.5 mm
2
Display
Digit height 10 mm (housing 48x24 mm)
14 mm (housing 96x48 mm, 96x24 mm, 72x36 mm)
Segment colour red (optional green, orange or blue)
Display range -1999 to 9999
Setpoints optical display flashing
Overflow horizontal bars at the top
Underflow horizontal bars at the bottom
Display time 0.1 to 10.0 seconds
Input Measuring
range
Ri Measuring fault Digit
min. -22…max. 24 mA 0/4–20 mA ~ 100 Ω 0.1 % of measuring range ±1
min. -12…max. 12 VDC 0–10 VDC ~ 200 kΩ 0.1 % of measuring range ±1
13
8. Technical data
