Content
1. Brief description 1
2. Assembly 1
3. Electrical connection and connection examples 2
4. Function description and operation 4
4.1. Programming software PM-TOOL 4
5. Setting up the device 5
5.1. Switching on 5
5.2. Standard parameterisation (flat operation level) 5
Value assignment for control of the signal input
5.3. Programming interlock 6
Activation/Deactivation of the programming interlock or change into extended
parameterisation
5.4. Extended parameterisation 7
Superior device functions like e.g.:
- rescaling of the input signals, , 7
- parameterisation of a TARA-function, 7
- zero point slowdown of the input signal, 7
- allocation of functions onto the navigation keys, 8
- adjustment of limit values for optical alarm, 8
- safety parameter for locking of the programming, 10
- input of supporting points for the linearisation of the input signals, 10
6. Reset to default values 11
Reset of the parameter onto delivery condition
7. Alarms / Switching points 12
Functional principle of the optical switching points
8. Technical data 13
9. Safety advices 15
10. Error elimination 16
