montwill M1 User Manual

Identification – Direct voltage / Direct current
Please state physical unit by order, e.g. m/min.
Options – breakdown of order code:
STANDARD TYPES ORDER NUMBER
Housing dimension:
96x48x38 mm (incl. plug-in terminal)
M1-1VR4B.0001.570xD
M1-1VR4B.0001.770xD
Housing dimension:
96x24x74 mm (incl. plug-in terminal)
M1-3VR4B.0001.570xD
M1-3VR4B.0001.770xD
Housing dimension:
72x36x100 mm (incl. plug-in terminal)
M1-6VR4B.0001.570xD
M1-6VR4B.0001.770xD
Housing dimension:
48x24x54 mm (incl. plug-in terminal)
M1-7VR4A.0001.770xD
M 1- 1 V R 4 B. 0 0 0 1. 5 7 0 x D
Standard type M-Line Dimension
D physical unit
Product range
1
Version
Housing size (BxHxD)
x internal version
96x48x25 mm 1
96x24x57 mm 3
Switching points
72x36x71 mm 6 0 no switching point
48x24x27 mm 7 2 relay outputs (only M1-6 devices)
Display type Protection class
Current, voltage V 1 without keypad, operation via PM-TOOL
7 IP65 / plug-in terminal
Display colour
Blue B
Supply voltage
Green G 5 230 VAC
Red R 7 24 VDC galv. isolated
Orange Y
Measuring input
Number of digits
1 0/4-20 mA, 0-10 VDC
4-digit 4
Analog output
Digit height
0 without
10 mm A
14 mm B
Sensor supply
0 without
Interface
without 0
