Appendix F - Specications
Type:
Programmable monophonic analog
synthesizer w/100 presets
Synth Engine:
Oscillator Section:
Oscillator 1:
Octave: 16’, 8’, 4’, 2’
Wave: Continuously variable
(triangle/sawtooth/square/pulse)
Level: 0 to 100%
Oscillator 2:
Frequency: +/- 7 semitones
Octave: 16’, 8’, 4’, 2’
Wave: Continuously variable
(triangle/sawtooth/square/pulse)
Level: 0 to 100%
Glide Rate: 0 to 100%
Oscillator Sync ON/OFF
Filter Section:
Cutoff: 20Hz to 16KHz
Resonance: 0 to Self-oscillation
Keyboard Amount: 0 to 100%
Filter Env. Amount: -100% to +100%
Overload: Variable pre and post
distortion, adds +6dB signal
boost at full level.
Envelope Generator Section (x2):
Attack Time: 0.001 to 10 seconds
Decay Time: 0.001 to 10 seconds
Sustain Level: 0 to 100%
Release Time: 0.001 to 10 seconds
Modulation Section:
LFO Rate: 0.2 Hz to 50 Hz
Source: LFO triangle, LFO square,
LFO sawtooth, LFO ramp,
Filter EG, Oscillator 2
Destination: Pitch, Oscillator 2,
Filter, Wave
Amount: 0 to 100%
Keyboard:
37 keys (C-C)
Transmits polyphonic MIDI Note On/Off
with velocity
Performance Controls:
Pitch Wheel: programmable, up to
+/- 12 semitones
Modulation Wheel: 0 to 100%
Fine Tune: +/- 3 semitones
Glide ON/OFF
Octave UP/DOWN: +/- 2 octaves
Output ON/OFF
Master Volume
Analog Edit Potentiometers (4)
User Interface:
LCD Display, 2 x 16 characters
Mode switches:
Master
Preset
Selection/Navigation controls:
Cursor
Enter/Store
Value encoder (with pushswitch)
Side Panel:
AC Power Inlet (universal power supply,
100-250VAC, 50-60 Hz,
power consumption: 12 Watts)
Power ON/OFF
Audio Out
Ext. Audio In (accepts +4dBu line level signal)
Control Voltage Inputs:
Pitch CV: -5 to + 5V
Filter CV: -5 to +5V
Volume CV: 0 to +5V
Keyboard Gate: +5V trigger
MIDI In, Out
Outputs:
Monophonic Audio Out (on side panel)
Headphone jack (1/4” TRS on front panel)
Dimensions:
26.75” x 14.75” x 6.75”
(679.5 mm x 374.7 mm x 141.5 mm)
Weight:
22lb (9.9 kg)
Operating System;
Flash upgradeable via MIDI SysEx
Specications subject to change without notice
