10
MOTHER-32 FIRMWARE UPDATE V2.0 April 2020
PAGE 1: ASSIGNABLE OUTPUT JACK
From this page, you can specify which Mother-32 signal is available via the ASSIGN output jack. The full
descriptions of each option can be found in the ASSIGNABLE OUTPUT: ASSIGN OUTPUT section of this manual.
PAGE 2: MIDI CHANNEL
Here you can set the MIDI Channel your Mother-32 will use to send and receive MIDI data.
PAGE 4: CLOCK INPUT PPQN (Pulse Per Quarter Note)
Here you can set the number of incoming clock pulses that will equal one quarter note.
NOTE: 24 PPQN is used by the DIN SYNC standard; 48 PPQN is used by some older drum machines
PAGE 3: TEMPO INPUT JACK MODE
This page allows you to specify the operating mode for the TEMPO input jack. The full descriptions of each
mode can be found under the CLOCK / TEMPO OVERVIEW: TEMPO INPUT section of this manual.
1: Accent
2: Sequencer Clock (Default)
3: Sequencer Clock / 2
4: Sequencer Clock / 4
5: Sequencer Step Ramp
6: Sequencer Step Saw
7: Sequencer Step Triangle
8: Sequencer Step Random
9: Sequencer Step 1 Trigger Output
10: MIDI Velocity
11: MIDI Channel Pressure
12: MIDI Pitch Bend
13: MIDI CC 1
14: MIDI CC 2
15: MIDI CC 4
16: MIDI CC 7
1: MIDI Channel 1
2: MIDI Channel 2
3: MIDI Channel 3
4: MIDI Channel 4
5: MIDI Channel 5
6: MIDI Channel 6
7: MIDI Channel 7
8: MIDI Channel 8
9: MIDI Channel 9
10: MIDI Channel 10
11: MIDI Channel 11
12: MIDI Channel 12
13: MIDI Channel 13
14: MIDI Channel 14
15: MIDI Channel 15
16: MIDI Channel 16
1: 1 PPQN
2: 2 PPQN
3: 3 PPQN
4: 4 PPQN
5: 5 PPQN
6: 6 PPQN
7: 7 PPQN
8: 8 PPQN
9: 9 PPQN
10: 10 PPQN
11: 11 PPQN
12: 12 PPQN
13: 13 PPQN
14: 14 PPQN
15: 24 PPQN
16: 48 PPQN
1: CV Input mode
2: Single Clock Advance mode
3: Analog Clock mode (revised in Version 2.0)
4: Step Address CV mode (added in Version 2.0)
