17
KEYBOARD
Moog One features a premium quality, 61-note keyboard with velocity sensitivity and aftertouch, which
are both available as modulation sources. Selectable sensitivity curves are also available to further
tailor the keyboard’s response to your personal playing style.
LEFT HAND CONTROLLER
Located at the left end of the
Moog One keyboard, the Left Hand
Controller (LHC) provides a number
of tools that enhance the playability,
performance, and expression of this
powerful instrument.
OCTAVE
The OCTAVE buttons allow the keyboard to be shifted up or down
by octave. Pressing both OCTAVE buttons at the same time will reset the
keyboard to its Default Octave.
NOTE: Press and hold both OCTAVE buttons to send a MIDI Panic (All Notes
and Controllers Off) message.
GLIDE
Glide delivers a smooth, continuous change in pitch when moving from
one note to the next. In addition to the GLIDE RATE knob and the GLIDE
ON button, Moog One offers three types of Glide, as well as additional
parameters for Legato, Glissando, and Gated Glide. Pressing the MORE
button on the Left Hand Controller brings these parameters into view in the
Center Console Display.
X/Y PAD
The X/Y PAD is a highly expressive, multidimensional touch surface
whose X and Y axes can be easily assigned to a variety of musically useful
destinations. There is also a third assignable axis that can sense Pressure
on the surface of the pad. The X/Y PAD can operate in either a latching or
non-latching manner as determined by the state of the X/Y HOLD button.
If the X/Y HOLD button is illuminated, the held value of the X/Y PAD
can be saved as part of a Preset, similar to the MOD wheel amount. Pad
pressure also sends a Gate On signal, available as a Control Source in the
Mod Matrix.
