37
MIDI MENU PARAMETERS (CONTINUED)
OUT FILTERS (CONTINUED)
PANEL
When set to ON (default) MIDI data from all the panel knobs and buttons is transmitted. When
set to OFF this data is not transmitted.
KNB NRPN/CC
Determines if the knobs and buttons on the Sub 37’s panel are transmitted via MIDI as
Non Registered Parameter Numbers or as CC messages. The choices are CC (default) and NRPN.
CC FORMAT
Chooses whether Continuous Controller data is sent using 7-bits or 14-bits (for greater precision). If
this level of MIDI precision is not needed, use 7-bit (default) as it requires less MIDI bandwidth.
CLOCK OPTIONS (MIDI MENU 3.4)
Highlight CLOCK OPTIONS >> and press the CURSOR button to enter the CLOCK OPTIONS sub menu.
SEND CLOCK
Dictates when the Sub 37 sends MIDI clock. OFF never sends MIDI clock. ARP sends MIDI
clock only when the Arp or Seq is running. ON sends MIDI clock all the time.
SEND ST/STP
When ON (default) MIDI Start and Stop messages are sent when starting and stopping the
sequencer. When OFF the Sub 37 will not send MIDI Start and Stop messages.
FOLLOW SPP
When ON the Sub 37 will follow the MIDI Song Position Pointer if MIDI Sync is active. MIDI SPP
allows a DAW to set the sequencer step to match the DAW’s song position, so that you can
start from beats other than the first beat and (in theory) stay in sync.
SYSEX (MIDI MENU 3.5)
Highlight SYSEX >> and press the CURSOR button to enter the SYSEX sub menu.
NOTE: During a SysEx dump the MIDI button will blink red until the transmission is finished.
BUFFER SEND
This command will send a MIDI SysEx Dump of the edit buffer’s current settings (this is the
preset or newly created sound as you have currently edited it, not the stored preset). To send
the buffer’s settings, press the CURSOR button highlighting the SEND parameter, and then
press either of the buttons to start the MIDI dump.
NOTE: When you send this type of SysEx file into a Sub 37, the data will go into its edit buffer,
but not yet be stored into a Preset location. You will still have go through the SAVE procedure
as outlined on page 13, which allows you to choose where you want to save this newly loaded Preset.
SEQUENCE SEND
This command will send a MIDI SysEx Dump of the edit buffer’s current sequence data (this
is the sequence as you have currently edited it, not the stored sequence). To send the buffer’s
sequence data, press the CURSOR button highlighting the SEND parameter, and then press
either of the buttons to start the MIDI dump.
NOTE: When you send this type of SyEex file into a Sub 37, the data will go into its edit buffer,
but not yet be stored into a Preset location. You will still have go through the SAVE procedure
as outlined on page 13. The advantage of this is that you can send Sequence dumps to any
preset without overwriting the saved preset’s sequence. To permanently save the sequence,
just save the preset.
