Moons' SSDC Series User Manual

41
Rev. 1.0
20/07/2020
SSDC-ECX-H/J Hardware Manual
400-820-9661
AM34SS-N-BR01 Series(With brake)
300
25
37
10
L
2
Ø14
102.7
38
13Flat
69.6
69.6
4-Ø6.5
86
Ø73.025
45.5
Model L Connector On Cable
AM34SS1DGA-N-BR01 88
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-0 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
15pcs
AM34SS3DGA-N-BR01 117.5
AM34SS5DGA-N-BR01 147
Specification of brake for NEMA34 motor
Model
Voltage Power Torque Reactive time Life Maximum speed
Insulation class
(VDC) (W) (N.m) (ms) (times) (rpm)
NEMA34 Brake
24 8.0 6.0 50 10000 5000 Class B
