STF-4X-ECX Hardware Manual
2.1.2 Current
When STF dr i ves wor k wi t h di �er ent mot or s, t he r ecommended power suppl y out put cur r ent
capaci t y under di �er ent suppl y vol t age i s shown i n bel ow t abl e. The STF dr i ve power suppl y
current is lower than the the winding currents because it uses switching amplifiers to convert a
high voltage and low current into low voltage and high current. The more power supply voltage
exceeds the motor voltage, the less current will be required from the power supply.
I t i s i mpor t ant t o not e t hat t he cur r ent dr aw i s si gni ficant l y di �er ent at hi gher speeds dependi ng
on the torque load to the motor. Estimating how much current is necessary may require a good
analysis of the load to the motor.
Drive Motor Voltage Uniaxial Current Drive Motor Voltage Uniaxial Current
STF05
AM8 24V Above 1.0A
STF10
AM23
24V Above 3.0A
AM11 24V Above 1.0A 48V Above 4.0A
AM14 24V Above 1.0A 70V Above 4.0A
AM17
24V Above 1.5A
AM24
24V Above 4.5A
48V Above 1.5A 48V Above 4.5A
AM23
24V Above 3.0A 70V Above 4.5A
48V Above 4.0A
AM34
24V Above 6.0A
AM24
24V Above 4.5A 48V Above 6.0A
48V Above 4.5A 70V Above 6.0A
2.2 Connecting the Power Supply
STF-4X products share a power connector. The first digit on the left side of the connector is the V+
of the power supply, and the second digit is the V- of the power supply.
(NOTE: Be careful not to reverse the wires. Reversing the connection may open the
internal fuse on the drive and void the warranty.)
V+ V-
Connect the chassis to the earth ground through the grounding screws.
To the Earth Ground.
