Moons' STF-EC Series - Page 21

21
Rev. 1.0
11/08/2017
STF-EC Hardware Manual
400-820-9661
IP65 type motor
Model Features
Lead
number
Length(mm)
Holding
Torque(N.m)
Current(A)
Rotor
Inertia(g.cm
2
)
Mass(Kg)
Mass Dielectric
Strength
AM23HS2450-03 IP65 Motor 4 61.7 1.2
4.5
260 0.6
500VAC/1Minute
AM23HS3455-05 IP65 Motor 4 83.7 1.8 460 1
AM24HS5401-44N IP65 Motor 4 94.5 2.5 900 1.4
AM34HD1404-13 IP65 Motor 4 98 5
7
1850 2.7
AM34HD2403-13 IP65 Motor 4 127.5 7.1 2750 3.8
Brake type motor
Model Features
Lead
number
Length(mm)
Holding
Torque(N.m)
Current(A)
Rotor
Inertia(g.cm
2
)
Mass(Kg)
Mass Dielectric
Strength
AM17HD4452-BR01 Brake Motor 4+2 60.3 0.25
1.8
38 0.38
500VAC/1Minute
AM17HD2438-BR01 Brake Motor 4+2 65.8 0.4 57 0.43
AM17HD6426-BR01 Brake Motor 4+2 74.3 0.5 82 0.51
AM17HDB410-BR01 Brake Motor 4+2 88.8 0.85 123 0.75
AM23HS2449-BR01 Brake Motor 4+2 95 1.2
2.2
260 0.8
AM23HS2450-BR01 Brake Motor 4+2 95 1.2 260 0.8
AM23HS04B0-BR01 Brake Motor 4+2 80 0.82
4.5
120 0.62
AM23HS84B0-BR01 Brake Motor 4+2 96 1.5 220 0.8
AM23HSA4B0-BR01 Brake Motor 4+2 118 2.3 390 1.2
AM24HS2402-BR01 Brake Motor 4+2 95 1.2
4.5
450 1.03
AM24HS5401-BR01 Brake Motor 4+2 126 2.5 900 1.6
AM34HD0404-BR01 Brake Motor 4+2 118.5 3
7
1100 2.2
AM34HD1404-BR01 Brake Motor 4+2 148 5 1850 3.3
AM34HD2403-BR01 Brake Motor 4+2 177.5 7.1 2750 4.4
Encoder type motor
Model Features
Lead
number
Length(mm)
Holding
Torque(N.m)
Current(A)
Rotor
Inertia(g.cm
2
)
Mass(Kg)
Mass Dielectric
Strength
AM17HD4452-E1000D Encoder motor 4 34.3 0.25
1.8
38 0.23
500VAC/1Minute
AM17HD2438-E1000D Encoder motor 4 39.8 0.4 57 0.28
AM17HD6426-E1000D Encoder motor 4 48.3 0.5 82 0.36
AM23HS0420-E1000D Encoder motor 4 41 0.6
2.2
135 0.42
AM23HS2449-E1000D Encoder motor 4 54 1.2 260 0.6
AM23HS3454-E1000D Encoder motor 4 76 1.8 460 1
AM23HS0421-E1000D Encoder motor 4 41 0.6
4.5
135 0.42
AM23HS2450-E1000D Encoder motor 4 54 1.2 260 0.6
AM23HS3455-E1000D Encoder motor 4 76 1.8 460 1
AM23HS5412-E1000D Encoder motor 4 111 3.2 750 1.5
AM24HS2402-E1000D Encoder motor 4 54 1.2 450 0.83
AM24HS5401-E1000D Encoder motor 4 85 2.5 900 1.4
AM34HD0404-E1000D Encoder motor 4 66.5 3
7
1100 1.6
AM34HD1404-E1000D Encoder motor 4 96 5 1850 2.7
AM34HD2403-E1000D Encoder motor 4 125.5 7.1 2750 3.8
