Moons' STF-EC Series - Recommended Motor

20
Rev. 1.0
11/08/2017
STF-EC Hardware Manual
400-820-9661
5.3 Recommended Motor
Standard type step motor
Model Features
Lead
number
Length(mm)
Holding
Torque(N.m)
Current(A)
Rotor
Inertia(g.cm
2
)
Mass(Kg)
Mass Dielectric
Strength
AM8HY2050-01N Single Shaft 4
31.5 0.015
0.5
2 0.05
500VAC/1Minute
AM8HY2050-02N Double Shaft 4
AM8HY4043-01N Single Shaft 4
47 0.037 4.2 0.09
AM8HY4043-02N Double Shaft 4
AM11HS1008-07 Single Shaft 4 31 0.05
1.6
9 0.1
AM11HS3007-02 Single Shaft 4 40 0.08 12 0.15
AM11HS5008-01 Single Shaft 4 51 0.12 18 0.2
AM14HYB401-03 Single Shaft 4 40 0.2 1 20 0.21
AM17HD4452-02N Single Shaft 4
34.3 0.25 1.8 38 0.23
AM17HD4452-01N Double Shaft 4
AM17HD2438-02N Single Shaft 4
39.8 0.4 1.8 57 0.28
AM17HD2438-01N Double Shaft 4
AM17HD6426-06N Single Shaft 4
48.3 0.5 1.8 82 0.36
AM17HD6426-05N Double Shaft 4
AM17HDB410-01N Single Shaft 4
62.8 0.85 1.6 123 0.6
AM17HDB410-02N Double Shaft 4
AM23HS0420-01 Single Shaft 4
41 0.6 2.2 135 0.42
AM23HS0420-02 Double Shaft 4
AM23HS2449-01 Single Shaft 4
54 1.2 2.2 260 0.6
AM23HS2449-02 Double Shaft 4
AM23HS3454-01 Single Shaft 4
76 1.8 2.2 460 1
AM23HS3454-02 Double Shaft 4
AM23HS0421-01 Single Shaft 4
41 0.6 4.5 135 0.42
AM23HS0421-02 Double Shaft 4
AM23HS2450-01 Single Shaft 4
54 1.2 4.5 260 0.6
AM23HS2450-02 Double Shaft 4
AM23HS3455-01 Single Shaft 4
76 1.8 4.5 460 1
AM23HS3455-02 Double Shaft 4
AM23HS04A0-01 Single Shaft 4
39 0.82 2.2 120 0.4
AM23HS04A0-02 Double Shaft 4
AM23HS84A0-01 Single Shaft 4
55 1.5 2.2 220 0.6
AM23HS84A0-02 Double Shaft 4
AM23HSA4A0-01 Single Shaft 4
77 2.3 2.2 390 1
AM23HSA4A0-02 Double Shaft 4
AM23HS04B0-01 Single Shaft 4
39 0.82 4.5 120 0.4
AM23HS04B0-02 Double Shaft 4
AM23HS84B0-01 Single Shaft 4
55 1.5 4.5 220 0.6
AM23HS84B0-02 Double Shaft 4
AM23HSA4B0-01 Single Shaft 4
77 2.3 4.5 390 1
AM23HSA4B0-02 Double Shaft 4
AM23HS04B0-03 Single Shaft 4
39 0.82 4.5 120 0.4
AM23HS04B0-04 Double Shaft 4
AM23HS84B0-03 Single Shaft 4
55 1.5 4.5 220 0.6
AM23HS84B0-04 Double Shaft 4
AM23HSA4B0-03 Single Shaft 4
77 2.3 4.5 390 1
AM23HSA4B0-04 Double Shaft 4
AM24HS2402-08N Single Shaft 4
54 1.2 4.5 450 0.83
AM24HS2402-11N Double Shaft 4
AM24HS5401-10N Single Shaft 4
85 2.5 4.5 900 1.4
AM24HS5401-24N Double Shaft 4
AM34HD0404-08 Single Shaft 4
66.5 3 7 1100 1.6
AM34HD0404-09 Double Shaft 4
AM34HD1404-06 Single Shaft 4
96 5 7 1850 2.7
AM34HD1404-07 Double Shaft 4
AM34HD2403-07 Single Shaft 4
125.5 7.1 7 2750 3.8
AM34HD2403-08 Double Shaft 4
