7
Rev. 1.0
11/08/2017
STF-EC Hardware Manual
400-820-9661
The connectors and other points of interest are illustrated below:
Ground Screws
Drive Status Display LED
RS-232
Communication Port
EtherCAT Communication Status
DisplayLED
EtherCAT ID
Motor Connector
Power Connector
I/O Connector
EtherCAT Link OUT
EtherCAT Link IN
Model
STF05-EC
STF10-EC
Drive Status Display LED
RS-232
Communication Port
EtherCAT ID
I/O Connector
Motor Connector
Power Connector
EtherCAT Link OUT
EtherCAT Link IN
EtherCAT Communication Status
DisplayLED
Ground Screws
Model
STF03-EC
STF06-EC
